ViewSonic CDE5561T-S 55" Full HD Touch Retail Monitor - Certified Refurbished
Description
The ViewSonic® CDE5561T 55’’ (54.6’’ viewable) Full HD ViewBoard® interactive flat panel display is a perfect solution for interactive business and educational classroom applications. This 10-point touch-enabled display, paired with PC-less operation and pre-installed ViewBoard® Lite annotation software, allows multiple users to simultaneously write or draw on the display’s 7H hardness surface using fingers or styluses. 350-nit brightness and wide viewing angles provide better visual performance in well-lit rooms, while Flicker-Free and Blue Light filter technologies create a more comfortable viewing environment. With a built-in dual core processor and 8GB internal storage, as well as integrated versatile connectivity including multiple HDMI, VGA, RS232, RJ45 and USB ports, this display provides powerful computing for annotation and multimedia playback without the need for a PC. The CDE5561T features a VESA-compatible design and can be placed on a wall mount, or on an optional trolley cart for flexible installation in classrooms and corporate meeting rooms.Features
- 55’’ (54.6’’ viewable) Full HD ViewBoard
- 1920 x 1080 Resolution
- 10-point multi-touch interactive screen
- Built-in ARM dual-core CPU with 8GB Storage
- Pre-installed annotation Software
- Enhanced viewing comfort
10-point Multi-Touch
With 10-point multi-touch capabilities, multiple users can simultaneously write or draw on the display's surface using styluses or their fingers – or both at the same time.
Built-in ARM Dual-core CPU with 8GB Storage
Equipped with a powerful dual-core processor and Mobile OS, this display provides smooth, lightning-fast computing and responsive touch capabilities. 8GB of onboard memory provides ample storage for files and multimedia content.
Pre-Installed ViewBoard® Embedded Software
ViewSonic’s easy-to-use ViewBoard Embedded software lets you write, highlight, edit, and transform documents and images on-screen in real-time. For more robust annotation options and educational templates for English, Math, and Science, a ViewBoard for Education software disc is included in the box and can be installed via an optional ViewSonic slot-in PC, or via an external PC connection.
Easy LAN Control
An integrated RJ45 connection allows you to remotely set up and manage display content from a PC or laptop. You can also remotely turn the display on or off, or adjust the volume and other settings, via a user-friendly on-screen interface.
Control Multiple Devices
RS232 offers local control for set-top boxes and other RS232 connected devices, directly with the display’s remote controller. HDMI CEC functionality offers local control of DVD players, sound systems, and other HDMI connected devices, directly with the display’s remote controller.
Enhanced Viewing Comfort
Flicker-Free technology and a Blue Light Filter help to eliminate eye strain from extended viewing periods.
Anti-scratch, Anti-glare Glass Faceplate
This display features 7H scratch-resistant surface hardness that ensures a durable, consistent, high-quality viewing experience. In addition, an anti-glare film improves screen visibility in bright environments.
Optional Trolley Mount
Although this display can be wall mounted for a solid and safe user touch experience, we also offer a trolley mount (LB-STND-003)* that provides the flexibility of a mobile display.
*Optional accessories (LB-STND-003) sold separately.
Specifications
| Display: | |
| Display Size (in.): | 55 |
| Viewable Area (in.): | 54.6 |
| Light Source: | LED |
| Resolution: | 1920 x 1080 |
| Aspect Ratio: | 16:09 |
| Static Contrast Ratio: | 1,200:1 |
| Backlight Life (Hours): | 50,000 |
| Brightness: | 350 cd/m2 |
| Response Time (Typical GTG): | 8ms |
| Viewing Angles: | 178º horizontal, 178º vertical |
| Panel Surface: | Anti-glare 7H tempered glass |
| Embedded Player: | |
| Android Version: | 4.2.1 |
| CPU: | ARM Cortex A9 Dual Core Processor |
| Memory: | 1.5 GB |
| Storage: | 8GB |
| Interface: | Setting, Annotation, Viewboard Lite, Interface |
| Audio: | |
| Internal Speakers: | 10W (x2) |
| Connector: | HDMI(3), VGA(1), RCA Audio In(3), SPDIF(1), USB 3.0(1), USB 2.0(3), RS232(1), CVBS(1), Ethernet LAN (RJ45)(1) |
| Power: | |
| Voltage: | 100-240 VAC, 50-60Hz |
| Consumption (typical): | 162W |
| Controls: | |
| On Screen Display: | Input, Volume, Backlight, Audio, Screen, Display, Adjust |
| Operating Conditions: | |
| Temperature: | 32-104º F (0 - 40º C) |
| Humidity (non-condensing): | 20-80% |
| Touch: | |
| Touch Technology: | Resistive |
| Touch Points: | 10-Point Touch |
| Weight (metric): | |
| Net Without Stand (kg): | 32.5 |
| Gross (kg): | 42 |
| Weight (imperial): | |
| Net Without Stand (lbs): | 71.7 |
| Gross (lbs): | 92.6 |
| Dimensions (metric) (WxHxD): | |
| Packaging (mm): | 1458 x 932 x 220 |
| Physical (mm): | 1304 x 800 x 97 |
| Dimensions (imperial) (WxHxD): | |
| Packaging (in.): | 57.4 x 36.7 x 8.7 |
| Physical (in.): | 51.3 x 31.5 x 3.8 |
| Mount: | |
| VESA Compatible: | 400 x 400 mm |
| General: | Certified Factory Recertified, 90 Day Warranty - Product has minor scratches and/or blemishes. |
| Warranty: | Certified Factory Recertified, 90 Day Warranty - Product has minor scratches and/or blemishes. |
| Recycle/Disposal: | Please dispose of in accordance with local, state or federal laws. |
| Package Contents: | CDE5561T display, power cable, VGA cable, audio cable, USB cable, RS232 adapter, remote control with batteries, stylus (x3), ViewSonic Wizard CD (User Guide and ViewBoard software) |
| Regulations: | FCC, cTUVus, CB, CE, RCM |
| UPC: | 766907845310 |
| Accessories: | CD-EW-55-01, CD-EW-55-02, LB-STND-003, LB-STND-005-3, NMP250-WL, NMP250-WU, NMP620-P10, NMP620-P10X, NMP709-P10_1, NMP709-P10_3, NMP709-P10_5, PD-IFP-001, STND-047, SW-020, SW-050, SW-051, SW-110, SW-111, SW-115, SW-UP-117, VB-STND-001, VIEWSTICK2, VIEWSTICK2-S, WMK-047, WMK-047-2, WMK-054, myViewBoard for Windows |
