Description
The CyberPower Intelligent LCD LE1000DG is a compact Battery Backup/ UPS (uninterruptible power supply) with line interactive topology. This model provides battery power and surge protection for desktop computers, workstations, networking devices, and home entertainment systems. The LE1000DG uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The model's compact design allows for horizontal or vertical placement. It can also be mounted on a wall. Features include PowerPanel® Personal Edition software to control and monitor the UPS, GreenPower UPS™ Bypass Design, and EMI/RFI Filtration.
Features
- 1000 VA / 530 W Capacity
- 1030 Joule Rating
- 120 VAC ± 5% Output
- 12 (6 surge, 6 surge + battery backup) Outlets
- Simulated Sine Wave
- Multifunction LCD
1030-Joule Rating
Absorbs a high amount of energy to adequately protect your equipment and prolong the life of the unit.
12 Surge-Protected Outlets
Include 6 with battery backup and 4 widely spaced outlets to protect the equipment in your home office.
Data Line Protection
Halts power surges in your phone line. HID-compliant USB port allows easy connectivity.
Greenpower UPS Bypass Design
Enables stable power to bypass the power supply's transformer for minimized energy consumption, noise and heat buildup. Ultraquiet design hushes operational noise.
AVR (Automatic Voltage Regulation)
Automatically regulates low voltages and overvoltage, within defined tolerances, for clean, consistent AC power.
Line Interactive Topology
Utilizes an autotransformer to regulate low-voltage situations, such as brownouts, and overvoltages, without switching to battery power.
Standby Topology
Switches to DC battery power when incoming power drops below or surges above safe voltage levels, and then inverts to AC power to run connected equipment.
Simulated Sine Wave Output
With pulse wave modulation generates a stepped, approximated sine wave for efficient power.
Powerpanel Personal Edition Software
Offers a user-friendly dashboard interface that allows you to easily control and monitor the power supply.
Multifunction LCD
Simplifies operation.
CyberPower $200,000 connected equipment guarantee.
Specifications
| General | |
| Product Name | 1000VA Battery Back-Up System |
| Brand | CyberPower |
| Model Number | LE1000DG |
| Color | Black |
| Color Category | Black |
| Power | |
| Capacity | 1000 VA / 530 W |
| Volt-Ampere Capacity | 1000 volt-amperes |
| Half Load Maximum Run Time | 10 minutes |
| Full Load Maximum Run Time | 2 minutes |
| Wattage | 530 watts |
| Joule Rating | 1030 joules |
| Features | |
| Number of Surge Outlets | 12 (6 surge, 6 surge + battery backup) |
| Phone Protection | Yes |
| Certifications & Listings | |
| ENERGY STAR Certified | Yes |
| UL Listed | Yes |
| Connectivity | |
| USB Port(s) | Yes |
| Topology | Line Interactive |
| Waveform | Simulated Sine Wave |
| Output | 120 VAC ± 5% |
| Plug type & cord | NEMA 5-15P, 5 ft. cord |
| Data line protection | Telephone(RJ11) |
| Management software | PowerPanel® Personal Edition |
| Dimension | |
| Product Height | 7 inches |
| Product Width | 12.2 inches |
| Product Length | 3.5 inches |
| Product Weight | 14.3 pounds |
| Cord Length | 5 feet |
