Description
Deliver your message at four times the resolution of 1080p with compatible content and sources and the CDE8600 86" 4K UHD Commercial LED Display from ViewSonic. It features a native resolution of 3840 x 2160 for enhanced clarity and has dual built-in 20W speakers that enable your message to be heard as well as seen. VGA, component, composite, and four HDMI inputs allow connection of traditional digital video sources, plus two USB ports support multimedia playback. A remote control, a power cable, a VGA cable, an RS-232 cable, an IR sensor cable, and an RS-232 daisy chain cable are included in the package for instant connectivity out of the box.
Features
- 4K UHD (3840 x 2160) Native Resolution
- 1200:1 Static Contrast Ratio
- 400 cd/m2 Brightness
- VGA, RCA & 4 x HDMI Inputs
4K UHD enhanced viewing experience with vibrant, clear images when paired with compatible content and source devices RS-232 input and output connectivity for simple management of multiple-display configurations from a single computer Dual built-in speakers allow your company's message to be heard as well as seen Embedded Android SoC allows you to install Android apps for rich content broadcasting Built-in browser displays internet content without the need for a PC Built-in multi-core media player with 16GB storage and USB playback function photos, music, and 1080p video can be quickly displayed on-screen directly from a USB drive without the need for a PC User-friendly scheduling interface available via on-screen display (OSD) setup features include time and date scheduling, ensuring that messaging, images, and videos run smoothly and on time ViewBoard Cast software enables content streaming from mobile devices onto the display over wireless or cable networks Included vController Software offers easy maintenance and intuitive interfaces for remote management via a PC server or laptop Flicker-free technology and blue light filter help provide a comfortable viewing environment Embedded LAN Optional Wi-Fi
Specifications
|
Display |
|
| Screen Size (Diagonal) | 85.6" |
| Resolution | 3840 x 2160 |
| Brightness | 400 cd/m² |
| Viewing Angle (H x V) | 178 x 178° |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1200:1 |
| Response Time | 8 ms (GtG) |
| Pixels Per Inch (ppi) | 51 ppi |
| Backlighting Technology | Direct LED |
|
Connectivity |
|
| Primary Connectivity Location | Display |
| Input Ports | 4 x HDMI 2.0 Audio, Video |
| 1 x 15-Pin VGA Video | |
| 1 x RCA Composite Video | |
| 1 x RCA Component Video | |
| 1 x 1/8" / 3.5 mm Audio | |
| Output Ports | 1 x HDMI 1.4 – Audio, Video |
| 1 x 1/8" / 3.5 mm – Audio | |
| 1 x TOSLINK Optical – Audio | |
| USB Ports | 2 x USB 3.1 / USB 3.2 Gen 1 Type-A |
| 1 x USB 2.0 Type-A | |
| Ethernet Ports | 1 |
| Control | RS-232C via DE-9/DB-9 |
| IR | |
| Wi-Fi | Wi-Fi Ready |
| Digital Media Slot | microSD (Unspecified Type) |
| Number of OPS/Expansion Slots | 1 |
|
General |
|
| TV Tuner | No |
| Lighting Lifespan | 30000 Hours |
|
Surface |
|
| Surface Treatment | Anti-Glare |
| Hardness Rating | 3H |
|
Audio |
|
| Built-In Speakers | Yes, 2 x 20 W |
|
Hardware |
|
| Processor | 1.4 GHz ARM MSD95E1D Dual-Core |
| Storage | 16 GB eMMC |
| RAM | 2 GB |
|
Electrical |
|
| Power Consumption | Maximum: 540.0 W |
| Typical: 300.0 W | |
| Standby: < 0.5 W | |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
|
Environmental |
|
| Operating Temperature | 41 to 104°F / 5 to 40°C |
| Operating Humidity | 20 to 80% |
| Certifications | FCC, UL, cUL, as per Manufacturer |
|
Physical |
|
| Wall Mounting | 700 x 400 mm |
| Bezel Thickness | 32.5 mm (Bottom/Right/Top/Left) |
| Duty Cycle | 16 Hours / 7 Days |
| Dimensions | 77.2 x 44.6 x 4.0" / 196.1 x 113.3 x 10.2 cm |
| Weight | 142.8 lb / 64.77 kg |
|
Packaging Info |
|
| Package Weight | 186.5 lb |
| Box Dimensions (LxWxH) | 83.5 x 49 x 10.9" |
