ViewSonic CDP4260-TL-S 42" Full HD Multi-touch Commercial Display - Certified Refurbished
Description
Display your business content in 1080p with the CDP4260-TL 42" Full HD Multi-Touch Commercial LED Monitor from ViewSonic. This business-ready monitor is endowed with a 6-point multi-touch 42" LED display and features a 1920 x 1080 native resolution for viewing detailed Full HD images without pixel loss. Integrated anti-glare technology allows you to view the screen in a variety of lighting conditions. This monitor's 450 cd/m2 brightness rating and 1,300:1 contrast ratio showcase its ability to handle light and dark on-screen images. As a digital-signage-capable display, this commercial monitor is suitable for use in settings such as retail and restaurant environments. This display features HDMI, VGA, DisplayPort, component video, and DVI ports for interfacing a variety of video sources. An Ethernet port is onboard for Internet connectivity. Dual 10W speakers are also built into the display for audio playback. This monitor is compatible with 400 x 200mm and 200 x 200mm mounts for wall placement.Features
- 1080p (1920 x 1080) Native Resolution
- 6-Point Multi-Touch Anti-Glare Display
- Up to 450 cd/m� Brightness Output
- 1300:1 Contrast Ratio
- 5mm narrow bezel design
- SuperClear technology for improved wide angle viewing
- Suitable Applications: Transportation, Retail, Hotels, Surveillance, Educations, Video walls
Advanced 6-Point Touch-Enabled Capability for Group Interaction With 6-point simultaneous touch technology, the CDP4260-TL encourages group interaction. Two or three users can simultaneously write or draw on the display's surface using the styluses or their fingers, or both at the same time. This multi-touch feature is suitable for educational and corporate meeting applications, as well as for scientific, GIS, and wayfinding applications. OPS Slot Compatibility Equipped with Intel's Open Pluggable Specification (OPS), the CDP4260-TL provides for cable-free integration and easy installation. In addition, the CDP4260-TL can connect to an integrated media player to provide an interactive multi-media experience. 24/7 Continuous Operation, 50,000-Hour Lifespan Featuring a lifespan of up to 50,000 hours (typical), the CDP4260-TL commercial display is designed for reliable and continuous 24/7 use. Full HD 1080p and 450 Nits Brightness The CDP4260-TL displays content in Full HD 1920x1080 resolution with 450-nit high brightness to deliver detailed pixel-by-pixel true-color performance. Efficient, User-Friendly Content Scheduling & Settings The CDP4260-TL provides an efficient, user-friendly scheduling interface via the on-screen display (OSD). Display setup features include time and date scheduling, repeat and shuffle settings, as well as content source settings for various inputs. 5x5 Daisy-Chain Support With integrated DVI output, the CDP4260-TL supports up to a 5x5 daisy-chain setup for multi-display installations. Additionally, 1080p signal transmission is supported in daisy-chain configurations. RS232 In/Out with IR Pass-Through for Easy Management RS232 input and output connectivity, along with IR pass-through functionality, provides for efficient management of multiple-display configurations from a single remote control. By using the RS232 output, daisy-chained configurations can be managed via a primary CDP4260-TL display. Versatile Inputs and One-Time Configuration Settings With a versatile selection of inputs, including HDMI, DVI, DisplayPort, component video, and VGA, the CDP4260-TL enables you to easily connect and use a variety of digital equipment. The one-time display installation and setup feature means your preferred source settings are never lost.
Specifications
| Display | |
| Type | Color TFT LCD module with LED backlight |
| Diagonal Size | 42.0" (106.7 cm) |
| Display Area (H x V) | 36.6 x 20.6" (93.0 x 52.3 cm) |
| Resolution | 1920 x 1080 |
| Viewing Angle (H/V) | 178° / 178° |
| Response Time | 12 ms |
| Light Source | Approximately 50,000 hours (typical) |
| Brightness | 450 cd/m² |
| Contrast Ratio (Typical) | 1300:01:00 |
| Aspect Ratio | 16:09 |
| Panel Surface | Anti-glare |
| Input Signals | 480i, 480p, 720p, 1080i, 1080p |
| Touch System | |
| Multi-Touch | Windows 7/8 for 2-6 point touch applications |
| Touch Method | Finger, Glove, and Stylus |
| Reading Height | ≤ 2 mm |
| Accuracy | ≤ 3.5 mm |
| Frame Rate | Up to 110 fps (depending on number of touches) |
| Reporting Rate | 10 - 15 ms |
| Communication | USB |
| Operating System | Windows 7, 8, 8.1, XP, Vista |
| Mac OS | |
| Linux | |
| Connectivity | |
| Inputs | 1 x HDMI |
| 1 x DVI | |
| 1 x VGA | |
| 1 x Component video | |
| 1 x DisplayPort | |
| 1 x 1/8" (3.5 mm) Audio | |
| 1 x Stereo RCA | |
| 1 x RS232 | |
| Outputs | 1 x DVI |
| 1 x Stereo RCA | |
| 1 x RS232 | |
| Other | 1 x USB |
| 1 x LAN | |
| 1 x AC power | |
| 2 x External speakers (left and right) | |
| Slot | 1 x OPS |
| Switch | 1 x Speaker |
| Audio | |
| Speakers | Internal: 2 x 10 W |
| General | |
| Controls | |
| Panel: | Power, Mute, Input, Vol -/+, Up, Down, Menu |
| Picture: | Brightness, Contrast, Sharpness, Black Level, Tint, Color, Color Temperature, Gamma Selection, Noise Reduction, Film Mode, Picture Reset |
| Screen: | Auto Setup, Auto Adjust, H Position, V Position, Clock, Clock Phase, Zoom Mode, Custom Zoom, Input Resolution, Screen Reset |
| Sound: | Balance, Treble, Bass, Audio Reset |
| PIP: | PIP Mode, PIP Size, PIP Audio, PIP H Position, PIP V Position, SUB input, PIP Reset |
| Configuration 1: | Off Timer, Schedule, Data and Time, Configuration 1 Reset |
| Configuration 2: | Language, OSD Turn Off, OSD H Position, OSD V Position, Information OSD, Monitor Information, Monitor ID, IR Control, Tiling, Power on Delay, Closed Caption, Configuration 2 Reset |
| Configuration 3: | Power Save, Heat Status, Screen Saver, Side Border Color, Configuration 3 Reset |
| Advanced Option: | Input Change, Terminal Setting, Scan Conversion, Color System, Scan Mode, Serial Control, LAN Setting, APM, Advanced Option Reset, Factory Reset |
| Power | |
| Voltage: | 100 - 240 VAC, 50 - 60 Hz |
| Consumption: | 120 W (typical) |
| Operating Conditions | |
| Temperature: | 32 - 104°F (0 - 40°C) |
| Humidity: | 20-80% (non-condensing) |
| VESA Compatibility | 400 x 200 mm and 200 x 200 mm |
| Bezel Width (Left / Right, Top / Bottom) | All Sides: 0.8" (19.5 mm) |
| Regulations | CE, CB, WEEE, FCC, UL/cUL, CU, ENERGY STAR 6.0 |
| Dimensions (WxHxD) | 38.4 x 22.4 x 3.1" (976.2 x 569.5 x 79.8 mm) |
| Weight | 54.6 lb (24.8 kg) |
| Packaging Info | |
| Package Weight | 53.0 lb |
| Box Dimensions (LxWxH) | 45.0 x 30.5 x 9.7" |
