Description
The ViewBoard IFP33 Series harmonizes a touch display with versatile software to create a comprehensive classroom solution for interactive and engaging learning. This interactive flat panel delivers exceptional image quality in 4K UHD, thanks to cutting-edge bonding technology that provides clearer colors, enhanced contrast, and reduced glare. The 40-point touchscreen interface, equipped with Ultra Fine Touch Technology, empowers students and teachers to collaborate seamlessly, using either their fingers or dual-tip pens, for an intuitive pen-on-paper experience. Powerful built-in front-facing speakers and a USB-C port sort out for a complete and convenient multimedia experience. The ViewBoard IFP33 Series is preinstalled with myViewBoard to offer advanced lesson delivery options for teachers and powerful device management tools for administrators.
Features
- Integrated with myViewBoard software
- Multi-tasking capabilities for enhanced lesson delivery
- Embrace simplicity and organization with the USB-C one-cable solution, offering 65W of Power Delivery
- Intuitive user interface and fast app launch for smooth operation
- Powered by Android 11
- 4K Ultra HD resolution (3840 × 2160) for crisp image clarity and detail
Specifications
| Display | |
| Panel Size | 65" |
| Panel Type | TFT LCD Module with DLED Backlight, IPS |
| Display Area (mm) | 1428.48 (H) × 803.52 (V) (64.5” diagonal) |
| Aspect Ratio | 16:09 |
| Resolution | UHD 3840x2160 (Pixels) |
| Colors | 1.07B colors |
| Brightness | 350 nits |
| Contrast Ratio | 5000:1 (max. with DCR enabled) |
| Response Time | 8ms |
| Viewing Angles | H=178, V=178 |
| Backlight Life | 50,000 Hours (8 hours of use per day) |
| Surface Treatment | Hardness: 7H, Anti-glare coating |
| Orientation | Landscape |
| Platform | |
| Processor | Quad-core ARM Cortex (A55*4) |
| RAM | 4GB DDR4 |
| Storage | 32 GB |
| Touch | |
| Type/Tech | Ultra Fine Touch Technology |
| Touch Point | 40 points touch |
| INPUT | |
| HDMI | HDMI-IN 2.0 x 3 (3840x2160 @60Hz) |
| RGB / VGA | x1 |
| Audio | x1 |
| RS232 | x1 |
| OPS | x1 (Optional Intel Standard OPS) |
| WiFi | x1 (Optional VB-WIFI-002/VB-WIFI-004/VSB-050) |
| OUTPUT | |
| HDMI | HDMI 2.0 x1 |
| Audio | x1 |
| SPDIF | x1 |
| LAN | |
| RJ45 | x2 |
| USB | |
| Type A | USB3.0: Front x2, Rear x2; USB2.0 x1 |
| Type B | x2 (Rear x1 + Front x1) |
| Type C | Front x1 (PD65W + DP1.2 + Data USB2.0 + 10M/100M sharing) |
| SPEAKERS | 16W x 2 |
| Top Camera Plate | Yes |
| Embedded OS | Android 11 |
| Special Features | |
| All-in-one USB port | Front “SmartPort™ USB” to all channels |
| Simple LAN sharing | 10/100M for Android & Slot-in PC |
| Light Sensor | Yes |
| Power | |
| Voltage | 100-240V AC |
| Consumption | On: 99W; Off: ≤ 0.5W |
| ERGONOMICS | |
| Wall Mount (VESA®) | 600 x 400 mm |
| OPERATING CONDITIONS | |
| Temperature (º C) | 0°C to 40°C |
| Humidity | 20% ~ 80% RH non-condensing |
| DIMENSIONS (W x H x D) | |
| Physical | 1488 x 897 x 88 mm / 58.6 x 35.3 x 3.5 in |
| WEIGHT | |
| Net | 77.1 lb / 34.95 kg |
| Gross | 98.5 lb / 44.7 kg |
| REGULATIONS | |
| Certifications | FCC/ICES003, EPEAT, CE EMC, LVD or CB, RoHS, Green BOM & RoHS DoC, ErP, REACH SVHC List & DoC, EEL, WEEE, BSMI, BIS |
