Description
The CPS1500AVR Smart App Equipped Uninterrupted Power Supply from CyberPower features eight battery- and surge-protected outlets complete with 900 watts of power. This uninterrupted power supply supports line-interactive technology to redirect the battery's DC current path from normal charging mode to supplying current when the power is lost. The replaceable battery provides up to 18 minutes of run time at half load and up to seven minutes of run time at full load, allowing your connected peripherals to be shut down properly.
Features
- 1500VA / 900W Simulated Sine Wave UPS
- 8 Outlets
- Line-Interactive Topology
- Automatic Voltage Regulation
- Rack Mount/Tower Convertible
Data Line Protection
Prevents power surges that travel through telephone, coaxial, and Ethernet lines from causing damage to electronics
Surge Protection
Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage
Line Interactive Topology
Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery
Automatic Voltage Regulation (AVR)
Provides clean, consistent AC power by automatically regulating low voltages and over voltages, within defined tolerances, when incoming utility power has minor fluctuations
Simulated Sine Wave Output
Uses pulse wave modulation to generate a stepped, approximated sine wave to supply cost-effective battery backup power for equipment that does not require sine wave output
Rack/Tower Versatility
Allows for horizontal rack or vertical tower installation
LED Status Lights
Indicate Power On and Wiring Fault
PowerPanel Business Edition Software (Included)
Provides IT professionals with tools for monitoring and managing the UPS and backup power, also offers remote management functionality
Applications
Department servers, corporate servers, workstations, network devices, and telecom installations
Specifications
|
General |
|
| Total Outlets | 8 x NEMA 5-15R |
| Protected Outlets | 8 (Battery and Surge) |
| Plug Type | NEMA 5-15P Offset Right-Angle |
| USB Charging Ports | None |
| SmartSlot Interface | None |
| Coax Protection | 1-In |
| 1-Out | |
| Data Line Protection | RJ11, RJ45 |
| Communications | Serial via DE-9/DB-9 |
| USB via Type-B | |
| Emergency Power Off (EPO) Support | Yes |
| Topology | Line Interactive |
| Transfer Time | 4 ms |
|
Power |
|
| Surge Energy Rating | 1840 Joules |
| Maximum Wattage | 900 W |
| Nominal Input Voltage | 120 VAC |
| Input Voltage Range | 90 to 140 VAC |
| Input Frequency | 50/60 Hz ± 3 Hz |
| Nominal Output Voltage | 120 VAC |
| Output Frequency | 50/60 Hz ± 1% |
| Load Capacity | 1500 VA |
| Waveform | Simulated Sine Wave |
|
Battery |
|
| Cells | 4 |
| Battery Capacity | 84 VAh |
| Full-Load Runtime | 7 Minutes |
| Half-Load Runtime | 18 Minutes |
| Charging Time | 8 Hours |
| User Replaceable | Yes |
| Replacement Battery | RB1270X4F |
| RB1270X4E (With serial numbers beginning with 'BB') | |
| Hot-Swap Support | Yes |
|
Environmental |
|
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 90% |
| Storage Temperature | 5 to 113°F / -15 to 45°C |
| Storage Humidity | 0 to 95% |
| Operating Altitude | 10,000' / 3048 m |
| Storage Altitude | 50,000' / 15,240 m |
| Certifications | FCC, UL, cUL, as per Manufacturer |
|
Physical |
|
| Cable Length | 10' / 3.05 m |
| Rackmount Size | 2RU |
| Dimensions (W x H x D) | 17.3 x 3.5 x 15.8" / 43.94 x 8.89 x 40.13 cm |
| Weight | 50.5 lb / 22.91 kg |
|
Packaging Info |
|
| Package Weight | 55.9 lb |
| Box Dimensions (LxWxH) | 21 x 20.2 x 11.5" |
