Description
The ST625U Standby UPS from CyberPower provides you with battery backup power and surge protection to ensure your devices stay operational in critical situations. It's equipped with eight NEMA 5-15R outlets, some of which are spaced to better fit larger plugs. The eight outlets deliver a surge rating of 890 joules, and four of these outlets are powered by an internal battery that grants connected equipment a full-load runtime of up to 2 minutes in the event of a power failure. Other notable features include onboard LED indicators and audible alarms to alert you when a situation does occur. In addition, the UPS comes with EMI/RFI filtration.
Features
- 625VA / 360W Simulated Sine Wave UPS
- 8 x NEMA 5-15R Outlets
- 2 x USB Type-A Ports
- EMI/RFI Filters
Battery Backup
Supplies power long enough for equipment to properly shut down when utility power fails, thereby preventing loss of data and minimizing component stress caused by a hard shutdown.
Surge Protection
Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
Simulated Sine Wave Output
Uses pulse-wave modulation to generate a stepped, approximated sine wave to supply cost-effective battery backup power for equipment that does not require sine wave output.
GreenPower UPS High-Efficiency Design
Reduces power consumption, utilizing a compact charger and power inverter to create an efficient backup power system for home and office use.
Specifications
|
General
|
|
| Total Outlets | 8 x NEMA 5-15R |
| Protected Outlets | 4 x NEMA 5-15R (Surge Only) |
| 4 x NEMA 5-15R (Battery and Surge) | |
| Plug Type | NEMA 5-15P |
| USB Charging Ports | 2 x USB Type-A (2.1 A) |
| Communications | USB via Type-B |
|
Power
|
|
| Surge Energy Rating | 890 Joules |
| Maximum Wattage | 360 W |
| Input Voltage Range | 96 to 140 VAC |
| Input Voltage Adjustable Range | 47 to 63 VAC |
| Nominal Output Voltage | 120 VAC |
| Output Frequency | 50/60 Hz ± 1% |
| Load Capacity | 625 VA |
| Circuit Breaker Rating | 15 A |
| Waveform | Simulated Sine Wave |
|
Battery
|
|
| Battery Capacity | 66 VAh |
| Chemistry | Lead-Acid |
| Full-Load Runtime | 2 Minutes |
| Half-Load Runtime | 9 Minutes |
| Charging Time | 1 to 8 Hours |
|
Environmental
|
|
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 95% |
| Storage Temperature | 5 to 113°F / -15 to 45°C |
| Operating Altitude | 9842' / 3000 m |
| Storage Altitude | 49,212' / 15,000 m |
|
Physical
|
|
| Cable Length | 5' / 1.52 m |
| Rackmount Size | None |
| Dimensions (W x H x D) | 9.8 x 5.8 x 3.2" / 248.92 x 147.32 x 81.28 mm |
| Weight | 5 lb / 2.27 kg |
|
Packaging Info
|
|
| Package Weight | 6.96 lb |
| Box Dimensions (LxWxH) | 14.25 x 8 x 4.5" |
