Description
Featuring 4K Ultra HD resolution and an advanced, next-generation touchscreen, the ViewSonic® ViewBoard® IFP8650 86" delivers incredible collaborative capabilities for 21st century boardrooms and classrooms. With integrated myViewBoard® annotation software and ViewBoard Cast™ streaming software, content creation and sharing has never been easier. What’s more, this ENERGY STAR certified display delivers optional slot-in PC capability for more computing-intensive interactive applications. A VESA-compatible design allows for installation on a wall mount, or on an optional trolley cart for more flexible installation in classrooms and meeting rooms.
Features
- ULTRA HD RESOLUTION: 86 Inch 4K Ultra HD (3840x2160p) interactive display
- ADVANCED TOUCH: 40-point multi-touch lets users write on the display with their fingers and stylus pens
- UPGRADED OPERATING SYSTEM: Android 11 operating system
- BETTER SOUND: Built-in 40W stereo soundbar delivers optimal sound
- INTEGRATED SOFTWARE: The myViewBoard suite includes Whiteboard, ViewBoard Cast, and more for better engagement
- FLEXIBLE CONNECTIVITY: Powerful quad-core processor and versatile connectivity options with 65W PD USB-C (HDMI, RJ45, and USB ports)
- REMOTE MANAGEMENT: Schedule updates and monitor device status with the built-in myViewBoard® Manager software
vLauncher 3.0 Interface
The upgraded ViewSonic vLauncher™ v3.0 Interface offers quick access to essential tools like myViewBoard®, cloud storage, and web browsing through a single, secure login. Customize your workspace with a redesigned desktop, improved side toolbar, and direct cloud access to Google Drive and OneDrive.
Intuitive and Ultra-Responsive Touchscreen
40-point touch allows multiple users to simultaneously write or draw on the display’s surface using styluses or their fingers, or both at the same time. Palm recognition technology minimizes errant touch inputs from palms, wrists, sleeves, etc., so that users can write and annotate freely.
myViewBoard™ Digital Whiteboarding Solution
myViewBoard digital whiteboarding software combines enterprise-level security with cloud-based portability and annotation tools to enhance the way your team connects and collaborates. Convenient features include secure single sign-on to your favorite cloud drives, easy conversion of common office files, QR code sharing, and much more.
ViewBoard® Cast Content Sharing Software
ViewBoard® Cast enables content to be streamed from mobile devices onto the display over wireless or cable networks. Multiple users can simultaneously annotate content (such as documents, cloud files, multimedia, etc.) on their devices in real time, and then stream and share that content onto the ViewSonic large format display.
myViewBoard Manager
myViewBoard™ Manager is a cloud-based management solution that empowers IT administrators to remotely monitor devices, manage apps, push out broadcasts and more within the myViewBoard ecosystem. myViewBoard Manager lets IT administrators seamlessly monitor and maintain individual displays across large organizations from a single control panel.
Enhanced Sound
An integrated 40W soundbar and subwoofer delivers incredible audio to every corner of the classroom.
SmartPort USB™
The ViewSonic SmartPort USB function allows devices to be plugged into any video source on the display, while still providing simultaneous access to the display’s front-facing USB ports.
USB-C with Power Delivery
This device easily connects to a PC, laptop or Chromebook via USB-C. In addition, USB-C connectivity provides up to 65W power delivery for convenient charging of your peripherals and accessories.
Specifications
| OS | Android 13 |
| GPU | ARM Mali-G51 |
| CPU | ARM Quad Core Cortex A73+A53 1.1GHz |
| Memory | 8GB |
| Storage | 64GB |
| Subwoofer | 16W (x1) |
| Internal Speakers | 12W (x2) |
| HDMI 2.0 In | 3 |
| HDMI Out | 1 |
| 3.5mm Audio Out | 1 |
| SPDIF Audio Out | 1 |
| USB 3.0 | 4 |
| USB 2.0 | 2 |
| USB Type C | 1 |
| Slot-in PC Slot | 1 |
| USB B Touch Port | 2 |
| RS232 | 1 |
| Ethernet LAN (RJ45) | 2 |
| WIFI Module Slot | 1 |
| Intel® OPS Slot In (80-pin) | 1 |
| Voltage | 100-240 VAC |
| Consumption (typical) | 175W |
| Stand-by | <.5W |
| Physical Controls | OSD / Remote Control / Annotation overlay |
| On Screen Display | Input, Volume, Backlight, Audio, Screen, Display, Adjust |
| Remote Control | Yes |
| Temperature | 32-104º F (0 - 40º C) |
| Humidity (non-condensing) | 10-90% |
| Tip Detection | Dual tips, 2.5mm and 8mm |
| Touch Points | 40-Point Touch |
| Touch Technology | Infrared |
| Physical (in.) | 77.1 x 45.7 x 3.5 |
| Physical (mm) | 1958 x 1160 x 90 |
| VESA Compatible | 800 x 600 mm |
| NFC | No |
| Regulations | cTUVus, FCC, ENERGY STAR 7.0, Mexico Energy, CE, CB, RoHS, ErP, WEEE |
| Ethernet LAN | (10/100/1000M) (Android 10/100, PC 10/100/1000) |
| Display Type | LCD |
| Screen Size | 86 |
| Viewable Area (in.) | 86 |
| Point technology | 40-Point |
| Viewing Angles | 178º horizontal, 178º vertical |
| Display Resolution | 3840 x 2160 |
| Response Time (Typical GTG) | 8ms |
| Aspect Ratio | 16:9 |
| Panel Surface | Anti-glare 7H tempered glass |
| Light Source | LED |
| Brightness | 400 nits (without cover glass) |
| Static Contrast Ratio | 1,200:1 |
