Description
From executive boardrooms to interactive huddle spaces, the ViewSonic® ViewBoard® IFP8662 86" enables limitless collaboration and endless innovation. Designed to help teams connect, collaborate, and create, this next-generation digital whiteboard delivers exactly what you need to move your ideas forward. A premium, state-of-the-art design features a bezel-less PCAP (projected capacitive) touchscreen with incredible 4K Ultra HD resolution. This highly accurate interactive screen provides for an incredibly natural and responsive handwriting experience. Using fingers, styluses, or both, multiple users can simultaneously write or draw on the huge 86” ViewBoard panel. What’s more, meetings and presentations start fast thanks to convenient one-wire USB-C connectivity.
Features
- ULTRA HD RESOLUTION: 86 Inch 4K Ultra HD (3840x2160p) with a bezel-less Interactive Display
- TOUCH PRECISION: 20-point PCAP touch technology lets multiple users write on the screen with their fingers and active styluses
- ONE CABLE SOLUTION: Convenient USB-C for connected devices
- BE HEARD: Built-in Microphone Array with echo cancellation and noise reduction technology
- POWERFUL COMPUTING: Optional addition of Slot-in PC provides increased functionality and speed
- REMOTE MANAGEMENT: Schedule updates and monitor device status with the built-in myViewBoard® Manager software
CRESTRON CONNECTED® V2 CERTIFIED
Enhance your remote management experience with greater speed, security and flexibility with your Crestron Connected V2 certified interactive display. This device is compatible with XiO Cloud® and other popular platforms for streamlined monitoring and management. Enjoy seamless backwards compatibility with systems that use Crestron Connected V1.0.
High-Performance 4K Touchscreen
Perfect for heavy usage in meeting rooms or classrooms, this display features an anti-glare and tempered glass screen for enhanced durability and clarity. 20-point PCAP (projected capacitive) touch technology delivers an ultra-smooth and natural handwriting experience, while 4K Ultra HD resolution provides incredibly vivid and lifelike images.
Sleek and Slim Design
Sleek, slim, and less than an inch thick, this premium LCD display looks as good as it performs. An edge-to-edge glass screen and bezel-less design enhance interactivity and viewing.
Convenient USB Type-C
Meetings and presentations start fast with single cable USB Type-C connectivity. Users can simply walk into a room, plug in their device, and immediately begin sharing info on the ViewBoard display. In addition to fast data, audio, and video transfer, USB Type-C also provides quick 65W charging and touch pass-through over a single cable.
Built-in Microphone Array
An integrated microphone array with echo cancellation and noise reduction technology delivers clear speech and sound during video conferences. The microphone can also pick up sound from up to 26 feet away.
Optional Slot-in PC
Based on your specific collaboration needs, you can choose an optional ViewSonic slot-in PC to provide additional computing power and advanced features. Options include Intel Core i5 and i7 processors.
myViewBoard™ Annotation Software
myViewBoard digital whiteboarding software combines enterprise-level security with cloud-based portability and annotation tools to enhance the way your team connects and collaborates. Convenient features include secure single sign-on to your favorite cloud drives, easy conversion of common office files, QR code sharing, and much more.
Device Management
myViewBoard Manager is an easy-to-use web-based application to help you securely set up, manage and maintain all of your displays from a centralized dashboard.
Specifications
| OS | Android 8.0 |
| CPU | ARM Quad Core Cortex A73 |
| CPU Processor Speed | 1.2GHz |
| Memory | 3GB |
| Storage | 32GB |
| Subwoofer | 15W (x1) |
| Internal Speakers | 12W (x2) |
| HDMI 2.0 In | 4 |
| HDMI 4K Out | 1 |
| 3.5mm Audio Out | 1 |
| SPDIF Audio Out | 1 |
| USB 3.0 | 5 |
| USB 2.0 | 1 |
| USB 3.1 Type C | 1 |
| Slot-in PC Slot | 1 |
| USB B Touch Port | 2 |
| RS232 | 1 |
| Ethernet LAN (RJ45) | 2 |
| WIFI Module Slot | 1 |
| Voltage | 100-240 VAC |
| Consumption (max) | 580W |
| Consumption (typical) | 160W |
| Stand-by | <0.5W |
| Temperature | 32-104º F (0 - 40º C) |
| Humidity (non-condensing) | 10-90% |
| Tip Detection | Finger or Active Pen |
| Touch Points | Windows: 20, Android: 20 |
| Touch Technology | Projective Capacitive |
| Physical (in.) | 77.2 x 46.1 x 3.1 |
| Physical (mm) | 1960.0 x 1171.0 x 80.0 |
| VESA Compatible | 800 x 600 mm |
| NFC | No |
| Regulations | CTUVus, FCC, Energy 8.0, EPEAT, Mexico, CE, CB, ErP, REACH, UKCA |
| Ethernet LAN | (10/100/1000M) (USB Type-C & Android 10/100, PC 10/100/1000) |
| Display Type | LCD |
| Screen Size | 86 |
| Viewable Area (in.) | 85.6 |
| Backlight Life (Hours) | 50,000 |
| Viewing Angles | 178º horizontal, 178º vertical |
| Display Resolution | 3840 x 2160 |
| Response Time (Typical GTG) | 8ms |
| Aspect Ratio | 16:9 |
| Panel Surface | Anti-glare 9H tempered glass |
| Light Source | LED |
| Brightness | 350 cd/m2 |
| Static Contrast Ratio | 1,200:1 |
